Advantages Analysis:
1. High Energy Density: The home 4.8kwh/5.12kwh lithium battery has a high energy density, which enables it to store more energy in a smaller package compared to other battery technologies.
2. Long Cycle Life: This battery pack has a long cycle life of up to 6000 cycles, 5 years warranty, service time more than 15 years.
3. Fast Charging: The battery pack can be charged quickly, which makes it ideal for applications that require frequent charging and discharging cycles.
4. Adaptability: compatible with most inverter in the market, such as Growatt, Goodwe, Deye, Luxpower, SRNE atc.for hybrid system or off-grid system
|
Description |
Parameters |
|
|
Model |
M15S100BL-U |
M16S100BL-U |
|
Array Mode |
15S |
16S |
|
Nominal Energy (KWh) |
4.8 |
5.0 |
|
Nominal Voltage (V) |
48 |
51.2 |
|
Charge Voltage (V) |
54.7 |
58.2 |
|
Discharge Cut-off Voltage (V) |
40 |
42 |
|
Standard Charging Current(A) |
20 |
20 |
|
Max.Continuous Charging Current (A) |
100 |
100 |
|
Max.Continuous Discharging Curent (A) |
100 |
100 |
|
Cycle Life |
≥ 6000Times@80%DOD, 25°C |
|
|
Communication Mode |
RS485/CAN |
|
|
Operating Temp |
Charging: 0~60°C; Discharging: -10°C~65°C |
|
|
Size(LxWxH) mm |
515x493x175 |
515x493x176 |
|
Net Weight (Kg) |
40 |
42 |
|
Package Size (LxWXH) mm |
550x520x230 |
550x520x230 |
|
Gross Weight (Kg) |
42 |
44 |
Target Market:
Our 51.2V 100AH lithium battery is suitable for a wide range of renewable solar energy applications, including residential and commercial solar power systems, off-grid power stations, RVs, boats, and telecoms. It is especially ideal for regions with unstable grid connections or frequent power outages, where a reliable and efficient energy storage solution is crucial.
