Floating Solar Mount is used in Floating PV System to fix solar panel on the water surface, with floater, mounting system, and anchoring, the anodized aluminium is used for the mounting components that makes the system durable and lightweight, thereby enabling its easy transportation and installation. Corrosion-resistant stainless steel is used for the system's fasteners that provides good strength and heat resistance to withstand harsh environmental conditions. The Floating Solar Mount is designed with more than 25 years' lifespan and provide with 10 years product warranty.
Features:
1: Modular design make installation easy and convenient.
2: Cover water surfaces to reduce evaporation.
3: Floater is made by HDPE which ensure long service time.
4: Strong weather ability, easy for operation and maintenance.
5: Decrease occupation of land resource.
6: Cool module and Increase 10%-15% generation.
7: Reduce water evaporation and save water resources
| Design Description:
1. Reduce water evaporation, and utilize the cooling effect of water to increase the power generation. 2. The bracket is made of aluminum alloy for fireproof. 3. Easy to install without heavy equipment; safe and convenient to maintain. |
|
| Installation Site | Water Surface |
| Surface Wave Height | ≤0.5m |
| Surface Flow Rate | ≤0.51m/s |
| Wind Load | ≤36m/s |
| Snow Load | ≤0.45kn/m2 |
| Tilt Angle | 0~25° |
| Standards | BS6349-6, T/CPIA 0017-2019, T/CPIA0016-2019, NBT 10187-2019, GBT 13508-1992, JIS C8955:2017 |
| Material | HDPE, Anodized Aluminum AL6005-T5, Stainless Steel SUS304 |
| Warranty | 10 Years Warranty |
It can greatly save land resources and will not have too much impact on the aquatic environment. It would have the high power generation efficiency because the wide water surface can effectively prevent the shadow from restricting the power generated by the photovoltaic module, and at the same time, the illumination area would always be even and much longer.
